Mud Logging Unit Mud logging unit used in oil and gas field.
SLS Mud Logging Unit is new generation logging equipment which is designed and manufactured by us, cooperated with famous International mud logging comany. SLS has advantages of a large amount of data, rich information, fast processing speed and accurate interpretation. The hardware and software configuration as well as the entire performance of the equipment have reached international leading level.
Module Type Technical Specifications Container DNV Certified Positive Pressure Explosion-Proof Container Suitable for zone I on rig site. DNV A0 grade,IEC79-13 standard. Data Acquisition System RS-485 Data Acquisition System Explosion proof product,40 analog signal channel,14 pulse signal channel. Chromatograph Fast Gas Chromatograph
Minimum detectable concentration: 10ppm
Cycle time: ≥30 s.
CO2 Analyzer SL-IR-II CO2
Analyzer Minimum detectable concentration: 0.2%.
Mud Logging Software Mud Logging Software System Alarm: rotating red light, buzzer113-138dB
Power: ≥50W
Alarm System: rotating red light
Buzzer: 113-138dB
Power: ≥50W
Other Module Directional Well Geologic Steering System (selectable) Modeling geological profile and stacking the well track. The remote collaborative analysis and decision making. Real Time Data Remote Transmission System(selectable) Wireless Network: 3G network, GPRS network, CDMA network.Data Transmission: synchronization with the on-site data.
Positive Pressure Explosion-Proof System Positive Pressure & explosion-proof with DNV certificate. A-60 level fire-proof Certificate,in compliance with IEC 60079-13 StandardApplicable to zone Ⅰ at wellsite Convenient installationAnti-jamming Ability Software Windows 2000 / XP platformData Sharing Through CDAEnglish & Chinese VersionRealtime Monitoring (numerical & curve)Engineering Program KitData Processing & Interpret ProgramOil & Gas Evaluation 7890
Chromatograph Detector: FID
Min detecting concentration: 10ppm (C1)
Baseline drift: ≤50pA/60 min
Baseline noise: ≤30pA
Repetition error: <3%
Components Analysis
Detector: FID
Min detecting concentration: 10ppm (C1)
Detecting scope: C1-nC5
Analysis circle: ≤30s
Separating degree: C1︰ C2 (concentration ratio: 100:1) Separating degree>1
Baseline drift: ≤50pA/60 min
Baseline noise: ≤30pA
Repetition error: ≤3%
CO2 Analyzer Based on infrared absorption principleDetection range:0.2%~100%
Response time :≤10s
Detection deviation:±2%FS
Drifting zero: ±2.5%FS
Repeatable deviation :<2%
Wireless data acquisition system
Explosion-proof design with IP67 protectionOver-current, over-voltage & short circuit protectionLow-power consumption, can work continuously for at least 20 days with a single charge Communication distance: more than 300m WITS protocol, compatible with various kinds of mud logging units
CNPS can ship the goods to you by Express, Air, or sea.
