Wireless electric torque sensor for mud logging unit The sensor is designed to measure the torque of rotary table. As a result, the operating state of drilling rig and bit can be also reflected. Based on the…
PRODUCT INTRODUCTION
During the use of the drill bit, as the drilling time increases, the damage of the formation to the drill bit becomes larger and larger, and the risk of accidents during the drilling process increases accordingly. The change of the torque parameter can be strengthened. The judgment of the drill bit minimizes the occurrence of drilling accidents.
PRODUCT SPECIFICATION
Supply voltage: 3.5-5VDC
Output: 0.5~2.5 V
Measuring range: 0-1000A
Frequency response: 0-50KHz
Measurement accuracy: ≤1% F.S
Working temperature: -40-70 ° C
Aperture: φ50mm
Protection level: IP 67
PRODUCT FEATURE AND APPLICATION
The electric torque sensor is composed of Hall elements and is used to measure the current change on the power cable of the electric drill. It is suitable for applications where the oil field and air pressure require non-contact measurement current.
PRODUCT DETAILS
The sensor explosion-proof box is assembled with the mounting bracket , and the g-type holder is used to fix the sensor in a suitable position on the site.The sensor installation area should avoid electromagnetic interference as much as possible, and the cavity should be sealed when the sensor is working.
PRODUCT QUALIFICATION
All sensors either are EX type or are intrinsically safe. Zone barriers are installed in the Unit. Using well-known brand products at home and abroad, the sensors of mud logging unit have the advantage of technical and performance indicators. At the same time, the service life is long.
CNPS can ship the goods to you by Express, Air, or sea .
